Tuesday, February 11, 2014

The Oil-and-Water of Website Design

Hear ye, hear ye: I have a meagre-but-workable knowledge of designing and maintaining small websites.

Over the years I've figured out some helpful website design/management practices that are probably pretty well known and obvious to real website managers, but I think are probably useful to anyone who likes to dabble. The underlying theme is layering and separation. Modularity. For example, the aesthetics of the website---the logo, the masthead---should be developed independently of coding (and preferably beforehand to help guide the coding). The coding itself naturally should separate into content, on-screen actions, and layout --- that is, e.g., your HTML, your javascript, and your CSS.

I'm going to skip a bunch of personal history and go straight to a case study: my lab's website. A few years ago I thought it would be good for my lab to have a web presence, so I thought: (1) We need a cool name, (2) We need a cool logo, (3) We need a cool website.

Turns out "cool" is defined such that "Terrestrial Lab" is a cool name and that this is a cool logo:


The definition is also flexible enough such that www.terrestrial-lab.org is a cool website. At the least, these will be our starting assumptions!

Before I made this website, my advisor often referred to our lab as the NJIT Middle and Upper Atmospheric Group. While that name was descriptive, I thought something like "Terrestrial Lab" was catchier. We're not studying rocks, oceans, volcanoes, or a plethora of other "terrestrial" features (hell, most of science fits under the "terrestrial" umbrella), so this name might seem remiss. But we do study space weather activity with a focus on the Earth's lower, middle, and upper atmosphere, and our work does make up the "terrestrial" component of our broader group, "Center for Solar-Terrestrial Research." So 1+1=2, and it's a great name!

With a hip new name, we could also have an easy-to-remember website URL. Our old website was TSMTM.net --- pretty dang easy to remember.....that is, if you're familiar with the -ospheres: troposphere, stratosphere, mesosphere, thermosphere, magnetosphere. But if you're anything other than an atmospheric scientist, I wouldn't feel bad if it just looks like a random string of letters. And, anyway, if you're anything like me, all you see at a glance is Teenage Mutant Ninja Turtles.

What's a hip new name without an eye-catching logo? I wanted something identifiable. Something simple and obvious from far. My idea was to make a logo that someone could mindlessly doodle in class. Something that would look good as a sticker, or on a T-shirt. Most importantly, it had to do all this while making us look like a serious group of scientists (we're actually just a bunch of clowns, so this is important!).

I started with a triangle: simple, serious, pointy. I played around with it on a piece of paper, adding bits of text until I got things looking like how I wanted. Then I went digital with Adobe Illustrator after the idea was already down. I had to play around with fonts until for a while, but I finally nailed it --- with printed T-shirts and all:




Great, but a logo by itself though isn't enough for a website: one also needs a masthead of sorts. Some kind of graphic. Something that is nice looking, professional, and somehow relevant. I had always thought the periodograms I produced with magnetometer data from Antarctica had an aesthetic appeal to them, so I started there. Overall, this should be a fun part. Just play around. This was my final product:



Ok, so we have a name, a logo, a main page masthead design. Now it's time to get your hands dirty and code. I'm going to assume you know a lot of basics (some HTML, a sprinkle of javascript, a dash of CSS) and just list some things that have helped me. For starters, my website looks like this:


It's important to realize that the TL website looked like this even when I had much less efficient coding practices. I did not yet fully appreciate the oil-and-water of website design --- the natural separation of content, on-screen actions, and layout! The focus of my pointers below is on efficiency, which has nothing to do with the final product, but everything to do with maintaining the final product without going insane.

1. Internal vs External Cascading Style Sheets: Formerly, I used internal cascading style sheets as my primary CSS with manual overrides in-line if necessary. This was fine when I first created the site as a proof-of-concept to show my advisor, but it quickly became awkward to maintain the site and develop new pages. If I wanted to change the CSS of one page, I'd have to manually go around and do it to the other pages as well---or just say "to heck with consistency!"

Solution: I updated my site's primary CSS to an external style sheet (.css file) and now can do manual over-rides both (locally) in-line, like I formerly could, and (page-globally) in the header using the <style> tag. (Look at the code below and/or Google these things if you want to learn more.)


2. Internal vs External Javascript:
Same story. I used to have it internal to each page on my site using the <script> tag. Although I rarely modify the javascript on the site, the individual pages look so much more cleaned up without it, which allows me to focus on a page's content. Each page now calls on an external .js file, which I only need to edit once if the need arises, not laboriously for each page.

3. The Navigation Bar: The meat of the TL website is the navigation bar at the top. It needs to remain constant as a user peruses the pages, which means it somehow has to exist within each page's HTML file. One terrible way to do it is to copy and paste the nav bar's HTML int each web page's HTML file. That's fine until you want to modify the nav bar --- to add new sections, delete old links, or edit the associated javascript or CSS. One small change to the nav bar requires manually going into each file and...oh man! How time-consuming. I used to actually do this. It was tiresome and oppressive, and it simply stamped out creativity and made website maintenance a chore.

Solution: Again, nothing new conceptually: separation of dynamic content from static content. It's possible to use an external HTML file for the nav bar and simply have each webpage of the TL site refer to that file. This dramatically changes the web design and management experience. How to do it? The answer is Server-Side Includes, which allows one HTML file to call upon an external HTML file. The only caveat for using SSI is that you must change your webpage extensions from .html (or .htm) to .shtml.

To learn basic SSI (which is likely all you need), the wikipedia article is good enough.

The code pasted below shows more than meets the eye. These few lines in an HTML file used to be tens of lines! Maybe more. I used to have both JS scripts and a huge CSS code in the head of every page. Now the website's server simply pastes it there before it gets sent to the user's browser. Same thing for the SSI and my nav bar. That's it. The server does all the hard work before this page ever goes live in someone's browser.

<head>
<title>CSTR - Terrestrial Laboratory</title>
<script type="text/javascript" src="TL_script1.js"></script>
<script type="text/javascript" src="TL_script2.js"></script>
<link rel="stylesheet" type="text/css" href="TL_in_style.css">
</head>


<body>
<!--#include virtual="topLinkBar.html"-->

#
# all other HTML code for the page
#

</body>

And, so the secret to sanity is the separation of seemingly singular suppositions! (And, of course, the mastery of alliteration.)
